Multi-Octave Mixer with SMA Female Connectors - 2 to 18 GHz
P/N: HM3014
Brand: Advanced Microwave
The Advanced Microwave HM3014 is multi-octave 2 to 18 GHz microwave mixer with an IF frequency range of DC to 1.5 GHz. The LO is driven with +7 to +12 dBm, and as an up or downconverter features typical conversion loss of 6 dB, L to I isolation of 25 dB, and L to R isolation of 30 dB. Maximum Input power is +20dBm.
|
