SMA Male to SMA Male Test Cable using HLL142 Low Loss Flexible Cable, Phase Stable vs. Temperature, 96 Inches

$246.63
Part #:
HLL142-S1-S1-96
Brand:
HASCO Components
Weight:
5.00 Ounces
Shipping:
Calculated at checkout
Current Stock:
5

Pricing by Quantity:

QUANTITY

1 to 9

Buy 10 - 49

Buy 50 or above

PRICE

$246.63

$243.43

$238.55

ADD TO WISHLIST
*** FOR QUANTITIES GREATER THAN CURRENT STOCK LEVELS CONTACT CUSTOMER SERVICE 1-888-498-3242
PRODUCT DETAILS
HASCO Part Number: HLL142-S1-S1-96

RF Cable Assemblies offered by HASCO Components are available in a variety of RF connectors and custom lengths for production and testing environments.  HLL142-S1-S1-96 is an RF test cable manufactured by HASCO Components.  The RF cable used is HLL142, it is designed to be phase stable against temperature. HLL142-S1-S1-96 has SMA Male to SMA Male connectors. This RF Assembly is rated up to 18 GHz. For additional technical information please refer to the datasheet. HASCO Cage Code: 0T8L4

pdf-icon.png« Click Here for the HLL142-S1-S1-96 Datasheetpdf-icon.png« Click Here for the HLL142-S1-S1-96 Outline Drawing

FEATURES:

  •  RoHS Compliant

  •  Low Loss, Low VSWR, High Reliability

  •  Phase Stable over Temp: 250ppm Max @ +22°C ~ +100°C

  •  Phase Stability Vs. Flexure: ± 3.6° @ 18GHz
    (When wrapped 360°around a 1.5 diameter mandrel)

  •  Available with Stainless Steel Armor

  •  Cable Insertion Loss: -.48 dB per Ft @ 18GHz

  •  Amplitude Stability: < ± 0. 3 through 18GHz

ELECTRICAL SPECIFICATIONS:

Raw Cable Max Frequency (GHz)

30









Capacitance (pF/ft)

82









Velocity Propagation (%)

80









RF Leakage @ 26.5 GHz (dB)

95









Time Delay (ns/Ft)

4.14









Impedance (Ohms)

50









Frequency (GHz)

2

6

10

18



Power CW (Watts)

510

285

220

165



Attenuation (Typ.)

0.271

0.661

0.825

1.188



Phase Stability vs. Flexure (°)

±0.4

±1.2

±2

±3.6



MECHANICAL SPECIFICATIONS:

Cable Max Dia. (Inch)

0.195

Min. bend radius (Inch)

1.0

Recommend Bend Radius (Inch)

2.0

Temperature Range (°C)
*High Temperature Strain Relief Available upon Request.

-55 to +85

Raw Cable Temperature Range (°C)

-55 to +200

MATERIALS AND FINISHES:

DESCRIPTION

MATERIALS

FINISH OR COLOR

Cable Jacket

FEP

Light Green

Marker

Mil-l-23053

Black or White

Contacts

BeCu

Gold Plated

Insulators

PTFE

None

Connector Bodies

Stainless Steel

Passivated

Connector Nuts

Stainless Steel

Passivated

Gasket

Silicon Rubber

A-A-59588





Test #1: SMA Male to SMA Male, 18 inches, DC - 18 GHz



Test #2: SMA Male to SMA Male, 18 inches, DC - 18 GHz
WARRANTY INFORMATION
*** FOR QUANTITIES GREATER THAN CURRENT STOCK LEVELS CONTACT CUSTOMER SERVICE 1-888-498-3242
Part No: HLL142-S1-S1-96
SMA Male to SMA Male Test Cable using HLL142 Low Loss Flexible Cable, Phase Stable vs. Temperature, 96 Inches

HASCO Part Number: HLL142-S1-S1-96

RF Cable Assemblies offered by HASCO Components are available in a variety of RF connectors and custom lengths for production and testing environments.  HLL142-S1-S1-96 is an RF test cable manufactured by HASCO Components.  The RF cable used is HLL142, it is designed to be phase stable against temperature. HLL142-S1-S1-96 has SMA Male to SMA Male connectors. This RF Assembly is rated up to 18 GHz. For additional technical information please refer to the datasheet. HASCO Cage Code: 0T8L4

pdf-icon.png« Click Here for the HLL142-S1-S1-96 Datasheetpdf-icon.png« Click Here for the HLL142-S1-S1-96 Outline Drawing

FEATURES:

  •  RoHS Compliant

  •  Low Loss, Low VSWR, High Reliability

  •  Phase Stable over Temp: 250ppm Max @ +22°C ~ +100°C

  •  Phase Stability Vs. Flexure: ± 3.6° @ 18GHz
    (When wrapped 360°around a 1.5 diameter mandrel)

  •  Available with Stainless Steel Armor

  •  Cable Insertion Loss: -.48 dB per Ft @ 18GHz

  •  Amplitude Stability: < ± 0. 3 through 18GHz

ELECTRICAL SPECIFICATIONS:

Raw Cable Max Frequency (GHz)

30









Capacitance (pF/ft)

82









Velocity Propagation (%)

80









RF Leakage @ 26.5 GHz (dB)

95









Time Delay (ns/Ft)

4.14









Impedance (Ohms)

50









Frequency (GHz)

2

6

10

18



Power CW (Watts)

510

285

220

165



Attenuation (Typ.)

0.271

0.661

0.825

1.188



Phase Stability vs. Flexure (°)

±0.4

±1.2

±2

±3.6



MECHANICAL SPECIFICATIONS:

Cable Max Dia. (Inch)

0.195

Min. bend radius (Inch)

1.0

Recommend Bend Radius (Inch)

2.0

Temperature Range (°C)
*High Temperature Strain Relief Available upon Request.

-55 to +85

Raw Cable Temperature Range (°C)

-55 to +200

MATERIALS AND FINISHES:

DESCRIPTION

MATERIALS

FINISH OR COLOR

Cable Jacket

FEP

Light Green

Marker

Mil-l-23053

Black or White

Contacts

BeCu

Gold Plated

Insulators

PTFE

None

Connector Bodies

Stainless Steel

Passivated

Connector Nuts

Stainless Steel

Passivated

Gasket

Silicon Rubber

A-A-59588





Test #1: SMA Male to SMA Male, 18 inches, DC - 18 GHz



Test #2: SMA Male to SMA Male, 18 inches, DC - 18 GHz
