Description
The WM4PD-2-26-S is an SMA female 4-way Wilkinson Power Splitter, Power Divider covering the continuous bandwidth of 2 GHz to 26 GHz by Werbel Microwave. The product features low insertion loss, high isolation and excellent VSWR performance. Tight phase matching and amplitude balance between outputs. Typical insertion loss of 1.4 dB. Typical isolation of 19 dB. Return loss of 19 dB typical. Amplitude balance of 0.23 dB typical. Phase balance of 7 degrees typical. This device is RoHS compliant. Werbel Microwave Cage Code: 78YZ0.
« Datasheet
« 3D Model
« Data Specifications
Item |
Specification |
|---|---|
|
Frequency Range |
2 to 26.5 GHz |
|
Impedance |
50 Ohms |
|
Return Loss (Port S) |
12 dB Min, 14 dB Typical (2 GHz to 8 GHz) |
|
Return Loss (Port 1-4) |
14 dB Min, 18 dB Typical (2 GHz to 8 GHz) |
|
Insertion Loss (above theoretical 6.0 dB) |
0.5 dB Typical, 1.0 dB Max (2 GHz to 8 GHz) |
|
Isolation |
16 dB Min, 19 dB Typical (2 GHz to 8 GHz) |
|
Amplitude Unbalance |
0.17 dB Typical, 0.40 dB Max (2 GHz to 8 GHz) |
|
Phase Unbalance |
2° Typical, 4° Max (2 GHz to 8 GHz) |
|
Input Power |
10 Watts Max |
|
Temperature Range |
-55°C to 85°C (Operating), -55°C to 100°C (Storage) |
|
Humidity |
10% to 90% non-condensing |
Mechanical Specifications
Item |
Specification |
|---|---|
|
Body |
Aluminum |
|
Connectors |
Stainless Steel |
|
Contact |
Gold plated BeCu |
|
Insulator |
PTFE |
|
Finish |
Green Paint |
- Connector Type:
- SMA
- Division:
- 4 Way
- Frequency, Max:
- 26.5 GHz
- Frequency, Min:
- 2 GHz
- Input Power:
- 10 Watts
- Type:
- Wilkinson Splitter
PRODUCT DETAILS
The WM4PD-2-26-S is an SMA female 4-way Wilkinson Power Splitter, Power Divider covering the continuous bandwidth of 2 GHz to 26 GHz by Werbel Microwave. The product features low insertion loss, high isolation and excellent VSWR performance. Tight phase matching and amplitude balance between outputs. Typical insertion loss of 1.4 dB. Typical isolation of 19 dB. Return loss of 19 dB typical. Amplitude balance of 0.23 dB typical. Phase balance of 7 degrees typical. This device is RoHS compliant. Werbel Microwave Cage Code: 78YZ0.
« Datasheet « 3D Model « Data Specifications
Item |
Specification |
|---|---|
|
Frequency Range |
2 to 26.5 GHz |
|
Impedance |
50 Ohms |
|
Return Loss (Port S) |
12 dB Min, 14 dB Typical (2 GHz to 8 GHz) |
|
Return Loss (Port 1-4) |
14 dB Min, 18 dB Typical (2 GHz to 8 GHz) |
|
Insertion Loss (above theoretical 6.0 dB) |
0.5 dB Typical, 1.0 dB Max (2 GHz to 8 GHz) |
|
Isolation |
16 dB Min, 19 dB Typical (2 GHz to 8 GHz) |
|
Amplitude Unbalance |
0.17 dB Typical, 0.40 dB Max (2 GHz to 8 GHz) |
|
Phase Unbalance |
2° Typical, 4° Max (2 GHz to 8 GHz) |
|
Input Power |
10 Watts Max |
|
Temperature Range |
-55°C to 85°C (Operating), -55°C to 100°C (Storage) |
|
Humidity |
10% to 90% non-condensing |
Mechanical Specifications
Item |
Specification |
|---|---|
|
Body |
Aluminum |
|
Connectors |
Stainless Steel |
|
Contact |
Gold plated BeCu |
|
Insulator |
PTFE |
|
Finish |
Green Paint |
