Directional Coupler 30 dB SMA Female, 0.5 to 2 GHz

$321.79
Part #:
WMC-0.5-2-30dB-S
Brand:
Werbel Microwave
Weight:
1.60 Ounces
Shipping:
Calculated at checkout
Current Stock:
10

Pricing by Quantity:

QUANTITY

1 to 9

Buy 10 - 24

Buy 25 - 49

Buy 50 or above

PRICE

$321.79

$312.14

$302.48

$292.83

ADD TO WISHLIST

Description

Werbel Part Number: WMC-0.5-2-30dB-S


The WMC-0.5-2-30dB-S is an SMA female Directional Coupler with a wide frequency range spanning from 0.5 GHz to 2 GHz by Werbel Microwave. Features 30 dB coupling response with broadband flat coupling response, high directivity, and excellent return loss performance. Designed, assembled, and tested in USA with lead free solder making it RoHS compliant. Coupling flatness ±0.50 dB typical. Insertion loss 0.35 dB max. Directivity of 26 dB typical. Return loss of 23 dB typical. Werbel Microwave Cage Code: 78YZ0.

Click Here to View Outline  « Datasheet     Click Here to View Outline  « 3D Model     Click Here to View Outline  « Data

 Specifications

Item

Specification

 Frequency Range

 0.5 to 2 GHz

 Impedance

 50 Ohms

 Coupling

 30 ± 1.0 dB

 Freq. Sensitivity (Flatness)

 ± 0.5 dB Typical, ± 0.75 dB Max

 Mainline Loss

 0.25 dB Typical, 0.35 dB Max

 Directivity

 23 dB Min, 26 dB Typical

 Return Loss (In & Out)

 20 dB Min, 24 dB Typical

 Return Loss (Coupling)

 20 dB Min, 23 dB Typical

 Input Power

 50 Watts Max

 Temperature Range

 -55°C to 85°C (Operating), -55°C to 100°C (Storage)

 Humidity

 10% to 90% non-condensing



 Mechanical Specifications

Item

Specification

 Body

 Aluminum

 Connectors

 Stainless Steel

 Contact

 Gold plated BeCu

 Insulator

 PTFE

 Finish

 Green Paint

*** FOR QUANTITIES GREATER THAN CURRENT STOCK LEVELS CONTACT CUSTOMER SERVICE 1-888-498-3242
Connector Type:
SMA
Coupling:
30 dB
Frequency, Max:
2 GHz
Frequency, Min:
0.5 GHz
Input Power:
50 Watts
Input Power, Max. Freq.:
50 Watts
PRODUCT DETAILS
Werbel Part Number: WMC-0.5-2-30dB-S


The WMC-0.5-2-30dB-S is an SMA female Directional Coupler with a wide frequency range spanning from 0.5 GHz to 2 GHz by Werbel Microwave. Features 30 dB coupling response with broadband flat coupling response, high directivity, and excellent return loss performance. Designed, assembled, and tested in USA with lead free solder making it RoHS compliant. Coupling flatness ±0.50 dB typical. Insertion loss 0.35 dB max. Directivity of 26 dB typical. Return loss of 23 dB typical. Werbel Microwave Cage Code: 78YZ0.

Click Here to View Outline  « Datasheet     Click Here to View Outline  « 3D Model     Click Here to View Outline  « Data

 Specifications

Item

Specification

 Frequency Range

 0.5 to 2 GHz

 Impedance

 50 Ohms

 Coupling

 30 ± 1.0 dB

 Freq. Sensitivity (Flatness)

 ± 0.5 dB Typical, ± 0.75 dB Max

 Mainline Loss

 0.25 dB Typical, 0.35 dB Max

 Directivity

 23 dB Min, 26 dB Typical

 Return Loss (In & Out)

 20 dB Min, 24 dB Typical

 Return Loss (Coupling)

 20 dB Min, 23 dB Typical

 Input Power

 50 Watts Max

 Temperature Range

 -55°C to 85°C (Operating), -55°C to 100°C (Storage)

 Humidity

 10% to 90% non-condensing



 Mechanical Specifications

Item

Specification

 Body

 Aluminum

 Connectors

 Stainless Steel

 Contact

 Gold plated BeCu

 Insulator

 PTFE

 Finish

 Green Paint

WARRANTY INFORMATION
*** FOR QUANTITIES GREATER THAN CURRENT STOCK LEVELS CONTACT CUSTOMER SERVICE 1-888-498-3242
Part No: WMC-0.5-2-30dB-S
Directional Coupler 30 dB SMA Female, 0.5 to 2 GHz

Werbel Part Number: WMC-0.5-2-30dB-S


The WMC-0.5-2-30dB-S is an SMA female Directional Coupler with a wide frequency range spanning from 0.5 GHz to 2 GHz by Werbel Microwave. Features 30 dB coupling response with broadband flat coupling response, high directivity, and excellent return loss performance. Designed, assembled, and tested in USA with lead free solder making it RoHS compliant. Coupling flatness ±0.50 dB typical. Insertion loss 0.35 dB max. Directivity of 26 dB typical. Return loss of 23 dB typical. Werbel Microwave Cage Code: 78YZ0.

Click Here to View Outline  « Datasheet     Click Here to View Outline  « 3D Model     Click Here to View Outline  « Data

 Specifications

Item

Specification

 Frequency Range

 0.5 to 2 GHz

 Impedance

 50 Ohms

 Coupling

 30 ± 1.0 dB

 Freq. Sensitivity (Flatness)

 ± 0.5 dB Typical, ± 0.75 dB Max

 Mainline Loss

 0.25 dB Typical, 0.35 dB Max

 Directivity

 23 dB Min, 26 dB Typical

 Return Loss (In & Out)

 20 dB Min, 24 dB Typical

 Return Loss (Coupling)

 20 dB Min, 23 dB Typical

 Input Power

 50 Watts Max

 Temperature Range

 -55°C to 85°C (Operating), -55°C to 100°C (Storage)

 Humidity

 10% to 90% non-condensing



 Mechanical Specifications

Item

Specification

 Body

 Aluminum

 Connectors

 Stainless Steel

 Contact

 Gold plated BeCu

 Insulator

 PTFE

 Finish

 Green Paint
