211-516SF,Southwest Microwave SMA Male Connector 4 Hole

SMA Male Connector 4 Hole .500" x .375" Flange - Accepts .018 Pin Dia., tested to 27 GHz

$42.01

Part #:

211-516SF

Brand:

Southwest Microwave

Weight:

0.50 Ounces

Shipping:

Calculated at checkout

Out of stock - Call for availability

For quantities greater than current stock levels, please contact customer service at 1-888-498-3242

Pricing by Quantity:

QUANTITY

1 to 9

Buy 10 - 24

Buy 25 - 49

Buy 50 or above

PRICE

$42.01

$35.99

$28.49

$23.28

PRODUCT DETAILS
Warranty Information

Description

The 211-516SF is a 4 Hole Flange SMA Male connector manufactured by Southwest Microwave. This SMA Male accepts a 0.018" Pin Diameter and will operate up to 27 GHz. The flange size is .500" x .375" All Southwest Microwave SMA connectors are made of Stainless Steel with either Gold Plated Brass or Beryllium Copper center contacts. This connector conforms to MIL-STD-348A and MIL-PRF-39012. Southwest Microwave Cage Code: 66049

« Click Here for the 211-516SF Datasheet

ELECTRICAL

Parameter	Specification
Frequency Range	DC - 27 GHz
VSWR	1.15:1 Max
Impedance	50 Ohms

MATERIALS

Item	Specification (Note: All plating thickness values are in micro-inches)
Body	Passivated Stainless Steel
Contact Pin	Beryllium Copper (BeCu), UNS C17300 Per ASTM B196, Gold Plated Per MIL-G-45204 or ASTM B488
Center Contact Capture	High Temperature Ultem 1000 Per ASTM D5205
Connector Interface	Per MIL-STD-348, Figs. 310-1 and 310-2

*** FOR QUANTITIES GREATER THAN CURRENT STOCK LEVELS CONTACT CUSTOMER SERVICE 1-888-498-3242

Connector 1 Mount:: 4 Hole
Frequency, Max:: 27 GHz
Frequency, Min:: DC
Gender:: Male
Mount Flange Size:: .500 X .375
Pin Diameter:: .018
Series:: SMA

PRODUCT DETAILS

« Click Here for the 211-516SF Datasheet

ELECTRICAL

Parameter	Specification
Frequency Range	DC - 27 GHz
VSWR	1.15:1 Max
Impedance	50 Ohms

MATERIALS

Item	Specification (Note: All plating thickness values are in micro-inches)
Body	Passivated Stainless Steel
Contact Pin	Beryllium Copper (BeCu), UNS C17300 Per ASTM B196, Gold Plated Per MIL-G-45204 or ASTM B488
Center Contact Capture	High Temperature Ultem 1000 Per ASTM D5205
Connector Interface	Per MIL-STD-348, Figs. 310-1 and 310-2
