HSS45A-29P-29P-48 2.92mm Male cable, HSS45A, 48 Inches

2.92mm Male to 2.92mm Male Test Cable using HSS45A Flexible Armored Cable, Phase Stable vs. Flexure, 48 Inches

$205.29

Part #:

HSS45A-29P-29P-48

Brand:

HASCO Components

Weight:

5.00 Ounces

Shipping:

Calculated at checkout

Out of stock - Call for availability

For quantities greater than current stock levels, please contact customer service at 1-888-498-3242

Pricing by Quantity:

QUANTITY

1 to 9

Buy 10 - 24

Buy 25 - 49

Buy 50 or above

PRICE

$205.29

$202.62

$199.14

$193.17

PRODUCT DETAILS
Warranty Information

Description

HASCO Part Number: HSS45A-29P-29P-48

RF Cable Assemblies offered by HASCO Components are available in a variety of RF connectors and custom lengths for production and testing environments. HSS45A-29P-29P-48 is an RF cable assembly manufactured by HASCO Components. The RF coax cable used is HSS45A, an armored phase stable against flexure RF cable. HSS45A-29P-29P-48 has 2.92mm Male to 2.92mm Male connectors. This RF Assembly is rated up to 40 GHz. For additional technical information please refer to the datasheet. HASCO Cage Code: 0T8L4

« Click Here for the HSS45A-29P-29P-48 Datasheet

« Click Here for the HSS45A-29P-29P-48 Outline Drawing

FEATURES:

RoHS Compliant
Low Loss, Low VSWR, High Reliability
Phase Stability Vs. Flexure: ± 8° @ 40GHz
(When wrapped 360°around a 2" diameter mandrel)
Armor: With good results in Resist compression, Resist torsion, Waterproof and Dustproof
Raw Cable: Cable Insertion Loss: -1.59 dB per Ft @ 40 GHz (Does not include Connectors)
Amplitude Stability: < ± 0.4 through 40 GHz

ELECTRICAL SPECIFICATIONS:

Max Frequency (GHz)	40
Capacitance (pF/ft)	96.44
Velocity Propagation (%)	70
RF Leakage @ 18 GHz (dB)
Time Delay (ns/Ft)	1.4
Impedance (Ohms)	50
Frequency (GHz)	2	6	18	26.5	40
Power CW (Watts)	81	48	21	17	10
Phase Stability vs. Flexure (°)	±0.2	±0.6	±1.86	±2.65	±8.0

MECHANICAL SPECIFICATIONS:

Armor Max Dia. (Inch)	0.256
Min. bend radius (Inch)	1
Recommend Bend Radius (Inch)	1.5
Temperature Range (°C)	-55 to +200

MATERIALS AND FINISHES:

DESCRIPTION	MATERIALS	FINISH OR COLOR
Cable Jacket	FEP	Blue
VA Armor	Stainless Steel +PUR	Blue
Marker	Mil-l-23053	White
Contacts	BeCu	Gold Plated
Insulators	PEEK	None
Connector Bodies	Stainless Steel	Passivated
Connector Nuts	Stainless Steel	Passivated
Gasket	Silicon Rubber	A-A-59588

*** FOR QUANTITIES GREATER THAN CURRENT STOCK LEVELS CONTACT CUSTOMER SERVICE 1-888-498-3242

Cable Diameter:: .256
Cable Length (Inch):: 48
Cable Series:: HSS45
Cable Type:: Low Loss
Cable Type:: Phase Stable
Connector 1 Gender:: Male
Connector 1 Series:: 2.92mm
Connector 1 Style:: Straight
Connector 2 Gender:: Male
Connector 2 Series:: 2.92mm
Connector 2 Style:: Straight
Flex Type:: Flexible
Frequency, Max:: 40 GHz
Frequency, Min:: DC
Jacket Material:: FEP
Velocity of Propogation (%):: 70
