HSB42-S1-S2-24 SMA Male to SMA Female cable, HSB42 Cable

SMA Male to SMA Female Test Cable using HSB42 Ultra Flexible Cable, Phase and Amplitude Stable vs. Flexure, 24 Inches

$119.90

Part #:

HSB42-S1-S2-24

Brand:

HASCO Components

Weight:

2.50 Ounces

Shipping:

Calculated at checkout

Current Stock:

For quantities greater than current stock levels, please contact customer service at 1-888-498-3242

Pricing by Quantity:

QUANTITY

1 to 9

Buy 10 - 24

Buy 25 - 49

Buy 50 or above

PRICE

$119.90

$116.30

$112.85

$109.45

PRODUCT DETAILS
Warranty Information

Description

HASCO Part Number: HSB42-S1-S2-24

RF Cable Assemblies offered by HASCO Components are available in a variety of RF connectors and custom lengths for production and testing environments. HSB42-S1-S2-24 is an RF cable assembly manufactured by HASCO Components. The RF coax cable used is HSB42, an ultra flexible amplitude stable against flexure RF cable. HSB42-S1-S2-24 has SMA Male to SMA Female connectors. This RF Assembly is rated up to 26.5 GHz. For additional technical information please refer to the datasheet. HASCO Cage Code: 0T8L4

« Click Here for the HSB42-S1-S2-24 Datasheet

« Click Here for the HSB42-S1-S2-24 Outline Drawing

FEATURES:

RoHS Compliant
Very flexible with bend radius of 1.95"
Good performance even after 20,000 flex cycles
Phase Stability Vs. Flexure: ± 2.95° @ 26.5 GHz
(When wrapped 360°around a 1.95" radius mandrel)
Available with Stainless Steel Armor
Cable Insertion Loss: -.79 dB per Ft @ 26.5 GHz
Excellent Amplitude Stability: < ± 0.1 dB through 26.5 GHz

ELECTRICAL SPECIFICATIONS:

Max Frequency (GHz)	26.5
Capacitance (pF/ft)	29.4
Velocity Propagation (%)	70
RF Leakage @ 18 GHz (dB)
Time Delay (ns/Ft)	1.40
Impedance (Ohms)	50
Frequency (GHz)	2	6	10	18	26.5
Power CW (Watts)	420	215	140	125	75
Phase Stability vs. Flexure (°)	±0.22	±.67	±1.11	±2	±2.95

MECHANICAL SPECIFICATIONS:

Cable Max Dia. (Inch)	0.195
Min. bend radius (Inch)	1.0
Recommend Bend Radius (Inch)	1.95
Temperature Range (°C)	-55 to +105

MATERIALS AND FINISHES:

DESCRIPTION	MATERIALS	FINISH OR COLOR
Cable Jacket	PVC	Blue
Marker	Mil-l-23053	White
Contacts	BeCu	Gold Plated
Insulators	PTFE	None
Connector Bodies	Stainless Steel	Passivated
Connector Nuts	Stainless Steel	Passivated
Gasket	Silicon Rubber	A-A-59588

Test #1: SMA Male to SMA Male, 30 inches, DC - 26.5 GHz

Test #2: SMA Male to SMA Male, 30 inches, DC - 26.5 GHz

*** FOR QUANTITIES GREATER THAN CURRENT STOCK LEVELS CONTACT CUSTOMER SERVICE 1-888-498-3242

Cable Diameter:: .195
Cable Length (Inch):: 24
Cable Series:: HSB42
Cable Type:: Amplitude Stable
Cable Type:: Low Loss
Cable Type:: Phase Stable
Connector 1 Gender:: Male
Connector 1 Series:: SMA
Connector 1 Style:: Straight
Connector 2 Gender:: Female
Connector 2 Series:: SMA
Connector 2 Style:: Straight
Flex Type:: Flexible
Frequency, Max:: 26.5 GHz
Frequency, Min:: DC
Jacket Material:: PVC
Velocity of Propogation (%):: 70
