Description
232-502SF is a SMA Female to SMA Female in series adapter manufactured by Southwest Microwave. This in series SMA to SMA coax adapter will operate up to 27 GHz. Adapters that have a male to female or plug to jack configuration are known as "connector savers." Typically, a low loss or low VSWR male to female adapter is placed on more expensive component connectors to prevent damage. Bulkhead adapters and right angle adapters are also available from Southwest Microwave. Southwest Microwave Cage Code: 66049
« Click Here for the 232-502SF Outline DrawingSpecifications
Item | Specification |
|---|---|
| Frequency Range | DC to 27 GHz |
| Impedance | 50 Ohms |
| VSWR | DC to 18.0 GHz: 1.10:1 MAX 18.0 to 27.0 GHz: 1.15:1 max |
| Temperature Range | -55°C to 165°C |
Mechanical Specifications
Item | Specification |
|---|---|
| Housing | Passivated Stainless Steel |
| Contact | Gold Plated Beryllium Copper Per MIL-G-45204 |
| Center Contact Capture | Ultem 1000 Per ASTM D5205 |
| Dielectric | PTFE Fluorocarbon Per ASTM D1710 |
- Adapter Body Style:
- Straight
- Connector 1 Gender:
- Female
- Connector 1 Mount:
- Inline
- Connector 1 Series:
- SMA
- Connector 2 Gender:
- Female
- Connector 2 Mount:
- Inline
- Connector 2 Series:
- SMA
- Frequency, Max:
- 27 GHz
- Frequency, Min:
- DC
- Type:
- In-Series
PRODUCT DETAILS
232-502SF is a SMA Female to SMA Female in series adapter manufactured by Southwest Microwave. This in series SMA to SMA coax adapter will operate up to 27 GHz. Adapters that have a male to female or plug to jack configuration are known as "connector savers." Typically, a low loss or low VSWR male to female adapter is placed on more expensive component connectors to prevent damage. Bulkhead adapters and right angle adapters are also available from Southwest Microwave. Southwest Microwave Cage Code: 66049
« Click Here for the 232-502SF Outline DrawingSpecifications
Item | Specification |
|---|---|
| Frequency Range | DC to 27 GHz |
| Impedance | 50 Ohms |
| VSWR | DC to 18.0 GHz: 1.10:1 MAX 18.0 to 27.0 GHz: 1.15:1 max |
| Temperature Range | -55°C to 165°C |
Mechanical Specifications
Item | Specification |
|---|---|
| Housing | Passivated Stainless Steel |
| Contact | Gold Plated Beryllium Copper Per MIL-G-45204 |
| Center Contact Capture | Ultem 1000 Per ASTM D5205 |
| Dielectric | PTFE Fluorocarbon Per ASTM D1710 |
