Product Image 1 - 2.4mm Male to 2.4mm Female Adapter - 50 GHz

2.4mm Male to 2.4mm Female Adapter - 50 GHz

$153.51
Part #:
1430-00SF
Brand:
Southwest Microwave
Weight:
0.50 Ounces
Shipping:
Calculated at checkout
Current Stock:
6

For quantities greater than current stock levels, please contact customer service at 1-888-498-3242

Pricing by Quantity:

QUANTITY

1 to 9

Buy 10 - 24

Buy 25 - 49

Buy 50 or above

PRICE

$153.51

$146.57

$132.72

$118.07

ADD TO WISHLIST

Description

Southwest Microwave Part Number: 1430-00SF

1430-00SF is a 2.4mm Male to 2.4mm Female in series adapter manufactured by Southwest Microwave. This in series 2.4mm to 2.4mm coax adapter will operate up to 50 GHz. Adapters that have a male to female or plug to jack configuration are known as "connector savers." Typically, a low loss or low VSWR male to female adapter is placed on more expensive component connectors to prevent damage.  Bulkhead adapters and right angle adapters are also available from Southwest Microwave. Southwest Microwave Cage Code: 66049


Click Here to View Outline  « Click Here for the 1430-00SF Outline Drawing

 Specifications

Item

Specification

 Frequency Range

 DC to 50 GHz

 VSWR

 DC to 27.0 GHz:            1.10:1 MAX

27.0 GHz to 40.0 GHz     1.15:1 MAX

40.0 GHz to 50.0 GHz     1.20:1 MAX

 RF Leakage

 < -100 dB

 Temperature Range

 -55°C to 135°C



 Mechanical Specifications

Item

Specification

 Housing & Coupling Nut

 STEEL, CRES ALLOY UNS-30300 PER ASTM A582 PASSIVATED PER QQ-P-35

 Contact

 BeCu UNS-C17300 PER ASTM B196 GOLD PLATE PER MIL-G-45204

 Bead Ring

 KEL-F PER MIL-P-46036, ULTEM 1000 PER ASTM-D-5205

 Retaining Ring

BeCu UNS-C17300 PER ASTM B196

 Gasket

 Silicone Rubber PER ZZ-R-765
*** FOR QUANTITIES GREATER THAN CURRENT STOCK LEVELS CONTACT CUSTOMER SERVICE 1-888-498-3242
Adapter Body Style:
Straight
Connector 1 Gender:
Male
Connector 1 Mount:
Inline
Connector 1 Series:
2.4mm
Connector 2 Gender:
Female
Connector 2 Mount:
Inline
Connector 2 Series:
2.4mm
Frequency, Max:
50 GHz
Frequency, Min:
DC
Type:
In-Series
PRODUCT DETAILS
Southwest Microwave Part Number: 1430-00SF

1430-00SF is a 2.4mm Male to 2.4mm Female in series adapter manufactured by Southwest Microwave. This in series 2.4mm to 2.4mm coax adapter will operate up to 50 GHz. Adapters that have a male to female or plug to jack configuration are known as "connector savers." Typically, a low loss or low VSWR male to female adapter is placed on more expensive component connectors to prevent damage.  Bulkhead adapters and right angle adapters are also available from Southwest Microwave. Southwest Microwave Cage Code: 66049


Click Here to View Outline  « Click Here for the 1430-00SF Outline Drawing

 Specifications

Item

Specification

 Frequency Range

 DC to 50 GHz

 VSWR

 DC to 27.0 GHz:            1.10:1 MAX

27.0 GHz to 40.0 GHz     1.15:1 MAX

40.0 GHz to 50.0 GHz     1.20:1 MAX

 RF Leakage

 < -100 dB

 Temperature Range

 -55°C to 135°C



 Mechanical Specifications

Item

Specification

 Housing & Coupling Nut

 STEEL, CRES ALLOY UNS-30300 PER ASTM A582 PASSIVATED PER QQ-P-35

 Contact

 BeCu UNS-C17300 PER ASTM B196 GOLD PLATE PER MIL-G-45204

 Bead Ring

 KEL-F PER MIL-P-46036, ULTEM 1000 PER ASTM-D-5205

 Retaining Ring

BeCu UNS-C17300 PER ASTM B196

 Gasket

 Silicone Rubber PER ZZ-R-765
WARRANTY INFORMATION
*** FOR QUANTITIES GREATER THAN CURRENT STOCK LEVELS CONTACT CUSTOMER SERVICE 1-888-498-3242
Part No: 1430-00SF
2.4mm Male to 2.4mm Female Adapter - 50 GHz

Southwest Microwave Part Number: 1430-00SF

1430-00SF is a 2.4mm Male to 2.4mm Female in series adapter manufactured by Southwest Microwave. This in series 2.4mm to 2.4mm coax adapter will operate up to 50 GHz. Adapters that have a male to female or plug to jack configuration are known as "connector savers." Typically, a low loss or low VSWR male to female adapter is placed on more expensive component connectors to prevent damage.  Bulkhead adapters and right angle adapters are also available from Southwest Microwave. Southwest Microwave Cage Code: 66049


Click Here to View Outline  « Click Here for the 1430-00SF Outline Drawing

 Specifications

Item

Specification

 Frequency Range

 DC to 50 GHz

 VSWR

 DC to 27.0 GHz:            1.10:1 MAX

27.0 GHz to 40.0 GHz     1.15:1 MAX

40.0 GHz to 50.0 GHz     1.20:1 MAX

 RF Leakage

 < -100 dB

 Temperature Range

 -55°C to 135°C



 Mechanical Specifications

Item

Specification

 Housing & Coupling Nut

 STEEL, CRES ALLOY UNS-30300 PER ASTM A582 PASSIVATED PER QQ-P-35

 Contact

 BeCu UNS-C17300 PER ASTM B196 GOLD PLATE PER MIL-G-45204

 Bead Ring

 KEL-F PER MIL-P-46036, ULTEM 1000 PER ASTM-D-5205

 Retaining Ring

BeCu UNS-C17300 PER ASTM B196

 Gasket

 Silicone Rubber PER ZZ-R-765
